balustrade posts for LSG with FTG
BAY 40-007-17-2 (German only)
safety and flexibility
The aesthetics of glass and metal is also an attractive part of the interior design. The high-quality balustrade systems from P+S can be perfectly adapted to different applications, e.g. as balustrade glazing or balconies.
AbP German National Test Certificate
balustrade posts for LSG with float glass
BAY 40-003-19-3 (German only)
brochures
Balustrade posts
in English and German
french balconies
French chique with German perfection
french balconies
The protection of a floor-level window or door area directly on the facade, also known as the “French balcony”, can be elegantly secured by combining glass and stainless steel fixtures. With hardware from Pauli + Sohn, security is ensured: our products are structurally tested, which makes planning and implementation much easier.
AbP German National Test Certificate
French balconies
BAY 40-005-22-3 (German only)
brochures
French balconies
Intelligent solutions for floor-to-ceiling windows
clamp fixtures
wiith safety
clamp fixtures
EPDM gaskets
new clamp fixtures system
- square shape, 48 x 45 mm
- glass thickness up to 12,76 mm
- in zinc, 304 and 316
- also approved with safety stud and safety plate
- clamping with only one EPDM-gasket form for different glass thicknesses
for 8 / 8,76 mm glass
for 10 / 10,76 mm glass
for 12 / 12,76 mm glass
| Art.-No. | 4845VA2-A2-V 4845VA2-A4-V |
|---|---|
| features |
|
| glass thickness | 8 / 8,76 mm 10 / 10,76 mm 12 / 12,76 mm |
| material |
|
| Art.-No. | 4847VA2-A2-V 4847VA2-A4-V |
|---|---|
| features |
|
| glass thickness | 8 / 8,76 mm 10 / 10,76 mm 12 / 12,76 mm |
| material |
|
product-info
new clamp fixtures
new system
clamp fixtures
semicircular shape
square shape
design and safety in unison
Particularly in the case of crash-proof glazing, the possibilities with P+S clamp fixtures are almost endless. In one point all variants are the same:
Their safety is excellent. Safety is a central issue, especially in public building projects. That is why one thing above all else counts here: competent support from a reliable partner. We received the first – and for years only – AbZ (approval) for clamp fixtures from the DIBt (German Institute for Construction Technology) in 1999.
Their safety is excellent. Safety is a central issue, especially in public building projects. That is why one thing above all else counts here: competent support from a reliable partner. We received the first – and for years only – AbZ (approval) for clamp fixtures from the DIBt (German Institute for Construction Technology) in 1999.
AbP and AbZ
clamp fixtures
widths between 1500 - 2100 mm
BAY 40-002-21-5
clamp fixtures
widths between 500 - 1500 mm
Z-70.2-28 (German only)
checklist
clamp fixtures
check list
cp-mini
no glass processing necessary
fastening system cp-mini
inspired by maximum effect
cp-mini is probably one of the most compact ways to combine maximum transparency with maximum security. These fixtures have also been thoroughly tested by independent institutes, so that cp-mini has a National Technical Test Certificate (AbP). Additional component tests or approval on an individual basis are therefore not necessary.
AbP German National Technical Certificate
glass support system cp-mini
BAY 40-008-16-1 (German only)
assembly instructions
9410VA-9424V cp-mini glass support system
assembly instructions cp-mini
checklist
cp-mini
Checkliste
point fixtures
according to the DIN and AbP
point fixtures
safety at its highest level
The German norm DIN 18008-4 provides planners and building owners a framework for designing crash-proof glazing with point fixtures according to this norm. Point fixtures according to DIN 18008-4 offer attractive possibilities for safe and elegant balustrade constructions.
AbP
German National Technical Certificate
point fixtures for glass infills
BAY 40-001-14-2 (German only)
checklist
point fixtures
check list
